MAUI is made for simplicity time saving shortcuts and intuitive dialogs simplify setup. MAUI is designed for touch all important oscilloscope controls are accessed through the intuitive touch screen. MAUI is the most advanced oscilloscope user interface. WaveSurfer 3000 oscilloscopes feature an advanced user interface with touch screen simplicity providing quick access to time saving debug tools. Analog and Digital Cross Pattern Triggering ◆ 16 Digital Channels with 500 MS/s Sample Rate But I´m quit sure, it wouldn´t be so on the z-model.◆ 200 MHz, 350 MHz, 500 MHz, 750 MHz bandwidths After holidays I check the fft function and decoding - Both are slowing down the system on the non-z model massive. If it weren´t so, I would come into trouble. Unfortunately and as I told before, it got only 2 math-channels. For example the calibration section, it allows you to choose between two calibrations and there is a system status which tells you, if it´s ready for it.(maybe it´s on the non-z too, I don´t remark it before). Now it´s a really good scope with superb building quality and some nice features. Systemperformance is much faster, the response of the UI is unlikely better - All this reminds me of my sds2k+.
Display is more "clear" and brighter, the touchpanel is much, much more responsive. Could check it only for a short time, but there are worlds between ws30z what the performance concerns. "Z".A little suffix makes a huge difference. It should arrive in the first february week - But surprise, it arrived today. BTW, the SDS5000X here in NA seems to currently ship with all options permanently unlocked, except for SENT and manchester. I know for sure which I'd prefer, but of course money is for real and it would come down to the discounts available. (Which should not be read to imply I don't think anyone does, only that like you I don't know why.) Just looking at MSRPs, the WS3024z comes in at about $1k more than the SDS5034X. In this sort of needle-in-haystack stuff a longer record can additionally be very useful.) If you don't do mixed-signal or digital circuitry, then I'm not sure why you'd need deep captures. It's not a huge deal in the scheme of things, you just have to reproduce failures over and over instead of performing analysis on a single capture of a failure. Haven't tested this on the SDS5000X to see if it has anything comparable to WaveScan or if I just have to trigger on it. (It could also search the record for anomalies, like RD# or WR# asserted without CS#, or a runt or glitch on these. More that it was a little slow decoding, panning, and tabulating them. I really only ever need longer acquisitions when looking at MCU mixed-signals, but never found the 10Mpts/ch on the WS3054 limiting. When I do I'll see how well it works with my assortment of LeCroy probes. I have an LPA10 on order, but am not sure when I'll receive it.
In direct comparison, I would prefer my sds2k+ what WS3024 without "Z" concerns. It got 4 math channels and the building look in general is slightly better.
The look and the features of the UI are slightly better as on siglent scopes, I hope sometimes the decoding features will be also on the siglent touchscreen models. It´s slow, it got some bugs, but it´s a nice scope for people which are patient one in general. Nevertheless: When you can get it for say under 1000 bucks and get it to work, congrats. Also the touchscreen response should be better - We will know it relatively soon, when we get the WS3024Z in the begining of 2022. You can see it on the buyable options, there is a power analyzer option which is only for the "Z" models avaible.
Wavesurfer 3024 plus#
Both are not to find on the WS3000Z models for what reason ever plus the "Z" marks that the hardware is more powerful. One is the missing of the helplines when you want to define the measuring gate, the other is when you are on longer timebases and push the "find triggerlevel" button, the scope will totally freeze.
Plus at least 2 bugs which are officially confirmed but not solved until today. Looks very nice (the UI), no question and it got some features I miss on my siglent sds2k+ (yoo-hoo siglent, wink, wink.) like 4 matchchannels at the same time, a way better (optically)designed decoder part including search function and some things more, nice as said. In general, it´s awfully slow, touchscreen´s response is slow - You got the feeling, that the MAUI UI is too heavy for the used hardware. First and to the OP, we got a WS3024 since 01/20218 at work and using it daily until it will be exchanged for the WS3024Z.
